Connecting the hob to the mains
Make sure that the data on the rating plate (V) matches your supply voltage.
To connect the hob to the mains power supply, do not use adapters, reducers, or branching devices as they
can cause overheating and fire.
If the cable is damaged or needs to be replaced, this must be done by a qualified electrician with
the correct tools.
The power supply cable must not touch any hot parts and must be positioned so that its temperature will not
exceed 75℃ / 167℉ at any point.
Check with an electrician whether the domestic wiring system is suitable without alterations. Any
alterations must only be made by a qualified electrician.
Installing the hob
Electrical connection must only be carried out by licensed specialist staff. An incorrect connection will
invalidate the warranty.
Cutting the worktop
Clean the worktop surface and make a proper cut-out (L*W):
(558~560)*(488~490) mm / (21.97~22.05)*(19.21~19.29) inch.
Be sure the thickness of the worktop surface is at least 30 mm / 1.18 inch.
A minimum of 50 mm / 1.97 inch space shall be preserved around the cut-out.
If the oven is a built-under type, route the cable along the rear corners of the oven to the main socket.
Note: Before carving, check that the dimensions indicated correspond to the
dimensions of the product.
www.iamzchef.com Email: info@iamzchef.com Whatsapp: +1 (838) 910 8317 Facebook: amzchefappliance
English
62
60 mm / 2.36"
30 mm /
1.18"
