Table of contents
Installation Instruction
Safety Precautions
Induction Cooking
Hints & Tips
Getting to Know Your Appliance
Setting the Hob
Flex Zone
Boost mode
Installation Instruction
After unpacking the appliance, ensure there is no visible damage. If it has been damaged during transit, DO
NOT USE, contact where you buy immediately.
Safe installation
Follow these safety instructions when installing the appliance. The safe operation of this appliance can only
be guaranteed if it has been installed to a professional standard in accordance with these installation
instructions. The installer shall be liable for any damage resulting from incorrect installation.
Built-under
■ If the hob is installed above refrigerators, dishwashers, non-ventilated ovens, or washing machines, a
minimum distance of 50 mm / 1.97 inch is needed.
■ Make sure that projecting parts such as the mains housing or the mains cable do not collide, e.g., with a
drawer.
Intermediate floor
If the hob is installed above a drawer, furniture compart-
ment or similar, or if the hob is accessible from below:
Install an intermediate floor of heat-resistant material (e.g.,
made of perforated plate to ensure ventilation) at a
minimum distance of at least 50 mm / 1.97 inch below the
hob.
When using adhesive, make sure that the temperature
resistance is 100℃ / 212℉.
Preparing the units
■ The worktop must be level, horizontal and stable.
■ Be sure the thickness of the work surface is at least 30 mm / 1.18 inch.
■ The fitted units, including wall finishing strips, must be heat-resistant to at least 100℃ / 212℉.
■ Niche cladding within 50 mm / 1.97 inch of the back wall must not be combustible(for example, tiles, stone).
■ Seal the cut surfaces to make them heat-resistant. This prevents the worktop from swelling as a result of
moisture.
Electrical connection
Electrical connection must only be carried out by licensed specialist staff.
An incorrect connection will invalidate the warranty.
www.iamzchef.com Email: info@iamzchef.com Whatsapp: +1 (838) 910 8317 Facebook: amzchefappliance
English
61
Pause
63
Child Lock
Timer
65
66
Cleaning & Care
67
Troubleshooting
68
Error Codes
69
Technical Specification
69
max. 5 mm / 0.2"
61
70
70
70
71
72
73
74
min. 50 mm
(min. 1.97")
max. 5 mm / 0.2"
