SuperFish ALU TECH UVC Gebrauchsanweisung Seite 3

NOTICE! The safety-switch is an extra security, it
ensures that the UV lamp is always switched off
automatically when disassembling (in case you
forgot to switch off the UV lamp).
Make sure the O-ring (M) is placed in the right
2
position.
Tighten the lock nut (H) hand-tight onto the
3
housing (C).
Mount the pipe clamps (N) at the location where
4
the UVC device should hang (take the length of the
cables into account).
Mount the electronic ballast (P) at the desired
5
location (take the length of the cables into
account).
Mount the couplings (S or T) with the lock nuts (R)
6
to the desired connections and close the other
connections with the cover plates (Q) and lock
nuts. Make sure the O-rings (M) are placed
correctly.
Place the device in the pipe clamps (N) and glue the
7
couplings between the pipes or connect the pond
hoses with hose clamps to the couplings.
Switch on the pump and check the whole assembly
8
for possible leaks.
Ensure that there is an adequate flow of water
9
through the device and then turn on the UVC
device by plugging in the power cord.
The transparent connection couplings (S or T) show
10
whether the UV-lamp (J) is lit.
NOTICE! To avoid UVC overheating, switch off the
UVC device when no water is flowing past it.
Maintenance
Check monthly if UV lamp is burning via the
transparent connection couplings (S or T).
Remove the plug from the socket before carrying
out maintenance!
The lamp is hot, wait 10 minutes after switch off
before opening the UVC device.
The UVC device should be cleaned twice a year. As
soon as algae growth increases, check the UVC
device and UV-lamp and clean the whole or
exchange the UV lamp as needed.
Ensure that the water is drained out of the UVC
device first, before opening the device.
Undo the lock nut (H) and remove the lamp holder
E
(L) with the UV lamp (J) and the quartz glass (K)
from the housing. If necessary, you can also replace
the lamp.
Carefully clean the quartz glass outer face with a
soft cloth and SuperFish Pump & UVC Clean. After
cleaning, thoroughly rinse the quartz glass with
clean tap water and check for damage. Replace the
quartz glass (Art. 06010295) if it shows any
damage (to prevent glass breakage).
NOTICE! The UV-lamp should be replaced annually,
as the lamp may still burn but no longer emits
enough UV radiation (maximum 8000 operating
hours). Replacement lamp Alu Tech 40 watt: SF
Tech UV TL-T5 40W (Art. 06010085), replacement
lamp Alu Tech 75 watt: SF Tech UV TL-T5 75W (Art.
06010090).
The inside of the housing (C) can be cleaned with a
brush, do NOT use any chemicals.
Carefully slide the quartz glass back into the
housing. At the other end of the housing there is a
support (U), ensure that the tip of the quartz glass
is in the support. If necessary, unscrew the locknut
at the other end of the housing and guide the
quarter glass into the support with your fingers.
Check that the O-rings (M) are positioned correctly.
Replace the lamp and lamp holder and tighten the
lock nut(s).
Switch on the pump and check the whole assembly
for possible leaks.
Then turn on the UVC device and check if the UV
lamp is working.
NOTICE! In the winter season, when the system is
not used, the UVC device should be removed to
avoid the risk of freezing.
GB
