4. Release the latch lever and slide pusher forward until it makes contact
with nail strip.
OPERATING THE TOOL
1.Add a few drops of tool oil daily into air inlet coupler before operating the
tool
2.Attach air hose with high flow quick disconnect.
3.Regulate air pressure to obtain the air pressure to within the
recommended working pressure range, (70~120P.S.I.G.)
4.Load fasteners into your tool following the instructions in this manual.
5.Test for proper fastener penetration by driving nails into sample piece of
wood. If fasteners do not achieve the desired depth, adjust the air pressure
to a higher setting until the desired depth is achieved. If you are using a
tool with a depth-control device, turn the thumb wheel until the desired
depth is achieved.
CLEARING A JAM FROM THE TOOL
1. Fastener Jammed in Fastener Discharge Area:Disconnect tool from
air hose Grab jammed fastener with pliers and remove nail. If tool is
equipped with a quick release nose cover, open the cover and remove the
jammed fastener. Reset cover.
2. Fastener Jam inside Magazine: Disconnect tool from air hose Pull
back on pusher until it latches at back of magazine.Remove jammed nail
from magazine, release pusher.
CLEANING TOOL
1. Always disconnect tool from air hose before cleaning. Remove any tar
build-up with WD-40Oil or a cleaning solution. Never soak tool in any
cleaning solution. This can cause damage to rubber parts and gaskets.
OPERATING TRIGGER VALVE SELECT SWITCH
CONTACT TRIP (BUMP FIRE) POSITION
- 8 -
