AS-5020 | ENGLISH
TRANSMITTER WINDOW
AS-5020-3_I-Manual_150x180_Fin7.indd 10
All manuals and user guides at all-guides.com
You can fix the window transmitter and the magnet
housing with included adhesive pads or screws.
When using one or more washers at the magnet
housing, e.g. for compensating window frames, we
recommend the window transmitter and the magnet
housing to be fastened with screws to avoid an
unwanted falling off. See drawing.
10
3a
3b
3c
U
2
3
U
