Kobra AF.2 Compactor Betriebsanleitung Seite 7

WARNINGS - IMPORTANT
BEFORE USING THE
INSTRUCTIONS FOR
WARNINGS.
Before plugging in the shredder make sure that the voltage
and the mains supply correspond to what is written on the
plate on the machine.
UNPLUG THE POWER CABLE IN THE FOLLOWING CASES:
-BEFORE CHANGING OR EMPTYING THE SHREDDED
PAPER COLLECTION BAG
-BEFORE LIFTING THE MACHINE FROM ITS BASE
-BEFORE ANY MAINTENANCE OR REPAIRS OR TOUCHING
THE INTERNAL PARTS OF THE MACHINE
NOMINAL VOLTAGE: CONTINUOUS OPERATION
NOMINAL VOLTAGE +10%: MAX. OPERATION 50 MIN.
FEATURES
Congratulations on purchasing an auto-feeder
KOBRA AF range document shredder.
The KOBRA AF.2 COMPACTOR model is also
equipped with an automatic paper compacting
system which reduces the volume of shredded
paper, increasing by 4 times the collection bag
capacity.
INSTALLATION (FIG.1)
Make sure power socket is easily accessible and
situated near to the machine. Take the machine out
of its packaging, position the machine head (A) on
the base (B). Open the door (C), slide the bag holder
frame (D) from its tracks (E).
Fit the plastic bag (F) which comes with the machine
onto the bag holder frame (D) and slide it back onto
its tracks (E). Push the frame right in and close the
door again.
OPERATING THE MACHINE (FIG.2)
Once the shredder has been plugged in, turn the
switch (H) to the "I" position. The light (G) will come
on for a few seconds and the machine will start a
shred cycle. If no documents to be shredded have
been inserted into the machine it will automatically
go on stand-by.
Now it is possible to shred documents at any time.
With the switch (H) in the "O" position, all functions
are switched off.
By putting the button (H) in the "R" position at any
time and with any kind of paper you can interrupt
shredding and extract the document by putting the
machine in reverse.
MACHINE, FIRST READ
USE AND THE FOLLOWING
PAY ATTENTION TO THE FOLLOWING WARNINGS
THE
PRINTED ON THE TOP OF THE MACHINE:
REFER TO THE OPERATING INSTRUCTIONS
WARNING!
SAFETY PRECAUTIONS
KEEP NECK TIES OR OTHER DANGLING
OBJECTS AWAY FROM THE THROAT
DO NOT PUT YOUR HANDS IN THE THROAT
AND THE CUTTING KNIVES
DO NOT ALLOW CHILDREN TO OPERATE
THE DEVICE
KEEP LONG HAIR AWAY FROM THE THROAT
DO NOT USE AEROSOL PRODUCTS OR
LUBRICANTS
MANUAL SHREDDING OF SINGLE SHEETS
Insert sheets in the throat (L) and the light indicator
(G) comes on and the machine starts shredding
automatically as two photocells inside the throat
detect the presence of paper and automatically
stop the shredding knives a few seconds after
shredding has finished.
If you insert a greater quantity of paper than the
shredding capacity, the machine will automatically
go into reverse and eject the excess paper.
Take the excess paper out of the throat in order to
free the photocells then insert a smaller amount of
paper and the machine will automatically restart
and finish shredding with a shred cycle.
It is advisable to limit jams caused by introducing
too much paper and to operate the machine below
maximum capacity in order to prolong the life of
mechanical parts and the life of the machine itself.
Continuous jams will cause damage to the driving
gear system not covered by warranty.
AUTOMATIC PAPER SHREDDING (FIG.3)
Open the top cover of the paper feeder tray as
shown in figure 3.. Insert a maximum of 300 sheets
of A4 paper in the feeder tray and in any case ensure
they are not higher than the maximum load mark (A).
Close the top cover, the machine automatically starts
shredding and automatically stops when shredding
is finished.
IMPORTANT:
The automatic function can be used for bound
blocks up to a maximum of 25 sheets. Provided the
type of staple used is no longer than 6 mm and the
7 KOBRA AF
