Salto XS4 One Installationsanleitung Seite 2

E i 750 x ROxx.. series
ALLEN 4 (x4)
TORX 20 (x6)
ALLEN 3 (x2)
BOLT (Depending on door thickness)
PAGE 2/12
54
42 57
TORX 20 (x1)
INSTALLATION GUIDE | XS4 One for DIN type locks
24
4
i
DOOR
THICKNESS LENGTH
32-47 mm 30 mm
45-60 mm 40 mm
60-75 mm 55 mm
75-90 mm 40 mm
90-105 mm 55 mm
105-120 mm 40 mm
E i 7 50 x RO xx.. series
E i 7 56 x RO xx..
E i 7 P0 x RO xx..
E i 7 P6 x RO xx..
E i 7 50 x SH xx..
E i 7 P0 x SH xx..
22
x 4
x 4
x 8
x 8
saltosystems.com
