GET SX1 PRO Installationsanleitungen Seite 4

REMEMBER TO WORK SAFELY AND KEEP THE ENGINE
TURNED OFF.
1.
Remove the front number plate
and the left side panel.
2.
Locate the original ECU
positioned under the left side
panel next to the airbox. If
necessary, refer to your bike's
service manual to locate it. Press
the lock tab on the original ECU
connector before disconnecting
it. Make sure to remove the
connector without damaging it.
3.
Insert the GET SX1 Pro ECU into
the rubber mount and connect it
to the original connector. Ensure
the connector is properly seated
and the lock tab is fully engaged.
4.
Connect the MAIN connector
of the ECU to the ECU connector
GL-264-AA
of the
wiring harness included in the
kit. Route the wiring harness to
the front of the bike, securing it
to the frame using zip ties (not
included in the kit).
EN
two-way
4
ECU ECU HARNESS
GL-264-AA
