1.5 Attach TV Bracket
Position your TV bracket configuration over your TV hole pattern - making sure the brackets are vertically centered and level.
Install using either the screw/washer (Flat Back) or screw/washer/spacer (Round Back / Extra Space) combination you selected for your TV.
IMPORTANT: Ensure TV bracket is securely fastened before moving on to the next step.
01
02
TV Bracket Configuration
A
(from page 7)
Illustrated with spacers
TV Bracket Configuration
B
(from page 7)
Illustrated with spacers
02
01
Flat Back
05
06
Round Back / Extra Space
07
06
05
9
