Troubleshooting
TV supplied spacers
a
: Use your TV supplied spacer for flat back TVs
to the wall).
NOTE: The M8x20mm screw will not work with the TV supplied spacer.
Verify with your TV manual that you can use the M8x20mm screws without the
TV supplied spacer.
FLAT BACK
CAUTION:
Avoid potential injury or property damage!
Use the correct screw length for adequate thread engagment.
Too Short
– Too short will not
hold the TV.
– Too long will
damage the TV.
16
TV Supplied
Spacers
(AND you want your TV closer
a
TV Supplied
Spacer
Too Long
Correct
If you are uncertain about your hardware selection, contact Customer
Service at US: +1 (888) 333-9952
(EMEA: +31 (0) 495 580 852; UK: +44 (0) 800 056 2853)
b
: Use your TV supplied spacer and spacer
● Round (irregular) back TVs
NOTE: The M8x20mm screw will not work with the TV supplied spacer or spacer
. Verify with your TV manual that you can use the M8x20mm screws without the
07
TV supplied spacer.
ROUND BACK
CABLES
CAUTION:
Avoid potential injury or property damage!
Use the correct screw length for adequate thread engagment.
Too Short
– Too short will not
hold the TV.
– Too long will
damage the TV.
07
for:
● Extra space needed for cables
b
TV Supplied
Spacer
07
Correct
Too Long
