1.2 Assemble Your TV Bracket
Determine which TV bracket configuration to use, A or B based on your TV
hole pattern measurements.
A
Dimensions in cm
TV Hole Pattern
Measurement
7.5 x 7.5
10.0 x 10.0
20.0 X 10.0
02
03
04
These smaller hole patterns only use TV bracket
Do not use the two TV bracket extenders
04
.
20.0
10.0
7.5
10.0
7.5
01
.
01
03
02
and four screws
and four nuts
B
Dimensions in cm
TV Hole Pattern
Measurement
20.0 x 20.0
02
3/8 in. (10 mm)
wrench
Assemble TV bracket extenders
onto TV bracket
02
Secure using four screws
03
and four
04
NOTE:
Nuts
are poly-locks and need to be forcibly tightened.
20.0
02
04
03
03
as illustrated.
01
nuts*
04
in the corner holes shown.
01
02
20.0
7
