Supplied Parts and Hardware
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact
Customer Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
STEP 1 Parts and Hardware
STEP 1 Parts and Hardware
M6 Extension
*
Bracket Screws
M6 x 12mm
03
x4
4
TV Bracket
01
x1
* †
M6 Nuts
*
Only needed for TVs with 20.0 x 20.0 cm
hole patterns
(7 ⁄ x 7 ⁄ in.)
†
Nylon locking bracket nuts are
M6
poly-locks and will need to be forcibly
04
x4
tightened.
TV Bracket
*
Extenders
02
x2
M4/M5
TV Screws
05
(qty. 4 each)
M4 x 35mm
M4 x 12mm
M5 x 35mm
M5 x 12mm
M6 x 35mm
M6 x 12mm
M8 x 20mm
Washers
06
(qty. 4 each)
M6/M8
07
Spacers
(qty. 4 each)
22 mm
