ULTIMATE SPEED OBDII USOBD A1 Bedienungsanleitung Seite 51

INFO: The screenshots (Fig . B to G) are for reference
only .
˜ Technical data
Model number:
Input voltage range:
Ambient temperature:
Humidity:
Altitude:
˜ Diagnostic Trouble Codes (DTCs)
OBD II Diagnostic Trouble Codes are codes that are stored
by the on-board computer diagnostic system in response
to a problem found in the vehicle . These codes identify a
particular problem area and are intended to provide you
with a guide as to where a fault might be occurring within a
vehicle . OBD II Diagnostic Trouble Codes consist of a five-
digit alphanumeric code . The first character, a letter, identifies
which control system sets the code . The other four characters,
all numbers, provide additional information on where the
DTC originated and the operating conditions that caused it
to set . Here below is an example to illustrate the structure of
digits .
50 GB/IE
HG12331
8 V to 25 V
0 ºC to +60 ºC
max . 95 %, non-condensing
max . 2,000 m above sea level
