3. From the moment the STATUS LED switches on the right colour, within < 5 s shortly press the
selected button (for example button "1"). STATUS LED switches off and switches on the selected
colour.
4. Shortly press the same transmitter button (button "1") again within <5 s.
5. The STATUS LED switches off to signal the button has been assigned correctly.
Two-button mode
1. Press PROG button shortly (1s). on receiver.
2. The STATUS LED switches on blue - you can assign the button to "switch on/off" function. If the
button is to realise different function, wait until the STATUS LED switches on the right colour
accordingly:
• Red - "colours selection" function,
• Light blue - "program selection" function.
3. From the moment the STATUS LED switches on the right colour, within < 5 s shortly press the
button which is to activate the function (for example button "1"). STATUS LED switches off and
switches on the selected colour.
4. Within<5 s shortly press the transmitter button which is to deactivate the function (for example,
button "2").
5. The STATUS LED switches off to signal the button has been assigned correctly.
REMOTE PROGRAMMING OF TRANSMITTERS
USING THE EXTA LIFE APP
Remote programming of transmitters allows assigning the transmitter buttons to the selected
receiver (channel) without physical access to it (it is not necessary to press the PROG. button on
the receiver). It is particularly comfortable, in case receivers are already mounted in a building
and access to them is difficult..
Requirements regarding remote programming of transmitters with SLR-22 controller::
• EXTA LIFE controller must be installed in the system,
• receivers, the transmitter will be remotely assigned to, must be powered and paired with a
controller,
• transmitters we want to assign to selected controllers remotely, also must be paired with a
controller
• during one step, it is possible to add remotely only one transmitter to realise selected function
of SLR-22 controller.
In order to assign remotely selected buttons of a transmitter to the SLR-22 controller, the
following steps are required:
1. Pair the selected receiver with the controller.
2. Pair the controller with a transmitter, which buttons you want to assign remotely to a receiver.
3. Choose the "Assign a receiver" (1) option by means of a transmitter.
4. From the list of all paired receivers, choose the receiver you want to remotely assign the
transmitter to (2).
5. In the 'Operation mode' field select the mode in which the transmitter should cooperate with a
receiver (3).
In case of SLR-22 single- and two-button modes are possible.
6. Choose buttons of a transmitter that will realise selected function.
7. Select the function to be realised by the button(s) - available functions are "switch on/off",
"Colour". "Floating" and "Program".
8. By pressing the "Transmitter preview" button, the system displays a transmitter with assigned
numbers of buttons (5).
