System Map: Front View with Display Open (Model A)
Figure 2 - Front View with Display Open (Model A)
1. Webcam
2. *Webcam LED
*When the webcam is in use, the
LED will be illuminated.
3. Built-In Array Microphone
3 1 3
2
4
Design I
15.6" (39.62cm)
5
6
7
4. Display
5. Power Button
6. Keyboard
7. Touchpad & Buttons
3 1 3
2
4
Design II
15.6" (39.62cm)
5
6
7
7
Note that the Touchpad and Buttons
valid operational area is that indicat-
ed within the dotted lines above.
7
