SETUP INSTRUCTIONS (continued)
Position this product away from the pool, so as to prevent
children from climbing on it and accessing the pool.
It is essential to change any damaged element or set of elements as soon as possible.
Use only parts approved by the manufacturer.
To inspect and change the filter cartridge, disconnect line cord, unscrew the pool inlet
nozzle (10) and strainer grid (11) from the strainer connectors and insert the hat-like plugs
into the strainer connectors before servicing the filter. After service, open the air release
valve, remove the plugs, allow any air to escape through the valve before tightening the
valve again and replace the pool inlet nozzle (10) and strain grid (11). The pump is now
primed with water again and may be turned on.
FILTER HOUSING
COVER
THREADED FILTER
HOUSING COLLAR
FILTER
CARTRIDGE
INSIDE
UPPER PUMP
CONNECTION
LOWER PUMP
CONNECTION
The power cord plug to the 220-240 volt electrical power source of the filter pump must be
positioned more than 3.5 m away from the pool walls. Check your local authorities to
determine the appropriate standard and requirements for "electrical installation of swimming
pools and basins equipment". The following table is for reference only:
Country/Region
International
Germany
The Netherlands
S AVE THESE INSTRUCTIONS
(58) MODEL FP604&FP638 FILTER PUMP ENGLISH SIZE: 4.875" X 7.25" PANTONE 295U 05/20/2024
WARNING
AIR RELEASE
VALVE (FILTER
POOL INLET
GAUGE+AIR
AIR ADAPTOR
RELEASE VALVE)
HOSE
HOSE CLAMP
France
Page 6
AIR JET
WATER LEVEL
VALVE
POOL INLET
JET NOZZLE
STRAINER GRID
(REMOVE)
INSIDE OF POOL
(ILLUSTRATION NOT TO SCALE)
Standard Number
IEC 60364-7-702
NF C 15-100-7-702
DIN VDE 0100-702
NEN 1010-702
58
English
A
(REMOVE)
PLUG
