Be sure you have access to water to fill the pool and chemicals for the water.
IMPORTANT: This filter pump is shipped with the air release valve (1) open (open the
air release valve if necessary). DO NOT replace the air release valve until you reach
STEP #8. Failure to follow these instructions will result in air trapped inside filter
housing; the motor will run dry, be noisy and malfunction.
1. Assemble above-ground-pool first. Carefully follow the pool's installation instructions.
2. Place the filter pump the length of the hose away from the pool wall where the lower
black protruding hose connection is "sticking-out". Ensure the filter pump is accessible
at all time for service and maintenance.
3. Insert the nozzle union (9 & 10) into the upper protruding hose connections, and then
attach the pool inlet air adaptor (15) to the upper protruding fitting. Screw the air jet
valve (14) over the pool inlet air adaptor (15). Then insert the strainer union (9 & 11)
into the lower protruding hose connections. The hoses (8) fit over the strainers inserted
into the connections.
4. There are two hoses to be connected to the filter pump hose connections. With hose
clamps (7), fasten one of the hoses (8) to the lower protruding hose connection
(marked "+" on the pool liner) and to the upper pump connection (marked "+").
5. Connect the second hose to the pool inlet air adaptor (15) and to the lower pump
connection. Make sure all the hose clamps (7) are tight. NOTE: Make sure the air jet
valve (14) is securely tighten onto the pool inlet air adaptor (15) and facing up.
6. In a counter-clockwise motion unscrew the threaded filter housing collar (12) from the
filter housing. Grasp and remove the housing cover (3). Check to see if a cartridge is
inside the housing. If yes, replace the cover, finger tighten the housing collar (12) back
onto the filter housing.
7. Fill the pool to a level of at least 1-2 inches above the top connection. The water will
automatically flow down into the pump.
8. When water starts flowing out of the air release valve hole, screw in the air release
valve back into the filter housing cover. Do not over tighten the valve. NOTE: Venting
the system is necessary for air to escape as the filter housing fills with water.
9. Connect the filter pump to the power outlet. The filter pump is now filtering the water.
Risk of electric shock. Connect this product only to a grounding type
receptacle protected by a ground-fault circuit interrupter (GFCI) or
residual current device (RCD). Contact a qualified electrician if you
cannot verify that the receptacle is protected by a GFCI/RCD. Use a
qualified electrician to install the GFCI/RCD, which has a maximum
rate of 30mA. Do not use a portable residual current device (PRCD).
10. Operate the filter pump until the desired water clarity is obtained.
NOTE: Never put pool chemicals directly into the filter pump. This may damage the
pump and void the warranty.
S AVE THESE INSTRUCTIONS
(58) MODEL FP604&FP638 FILTER PUMP ENGLISH SIZE: 4.875" X 7.25" PANTONE 295U 05/20/2024
SETUP INSTRUCTIONS
WARNING
Page 5
