Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
36mm
Ø 60mm
1" 27/64
Ø 2" 23/64
Ø 40mm
Ø 1" 37/64
68mm
2" 43/64
Ø 54mm
Ø 2" 1/8
440mm
17" 21/64
3/8" GAS (EU)
3/8" GAS (EU)
9/16" NPT (USA)
3/8" NPT (USA)
Ø 70mm
Ø 2" 3/4
5mm
13/64"
18mm
45/64"
13mm
33/64"
max. 60mm
2" 23/64
3/8" GAS (EU)
9/16" NPT (USA)
Funzionamento
Fonctionnement
Sostituzione della cartuccia
Changing of the control cartridge
Remplacement de la cartouche
Austausch der Steuerpatrone
-2-
Operation
Betrieb
Fredda
OPEN
Cold
90°
Calda
Hot
= 2 mm
5/64"
= 25 mm
63/64"
