PPEVTEST
Electrical Specifications
Accuracy is given as ±(% of reading + counts of least significant digit) at 23°C ± 3°C,
with relative humidity Less than 70% R.H., and is specified for 1 year after calibration.
ACV Function
• ACV and ACA specifications are ac coupled, true RMS.
• For square wave, accuracy is unspecified.
• For non-sinusoidal waveforms, Additional Accuracy by Crest Factor (C.F.):
Add 1.0% for C.F. 1.0 to 2.0
Add 2.5% for C.F. 2.0 to 2.5
Add 4.0% for C.F. 2.5 to 3.0
• Max. Crest Factor of Input Signal : 3.0 @ 3000 counts
• Frequency Response is specified for sine waveform.
AC Voltage
Range
1000.0V
Input Impedance : 10MΩ// less than 100pF
Frequency Response : 50Hz to 1kHz
Overload Protection : AC/DC 1000V
DC Voltage
Range
1000.0V
Input Impedance : 10MΩ
Overload Protection : AC/DC 1000V
R Resistance(2-Wire)
2W
Range
40.00Ω
400.0Ω
4.000kΩ
40.00kΩ
* Add 3dgt when < 1.00Ω
* Add 10dgt in 20mA output current mode
* Add 0.5%+5D in Automatic bi-directional test mode
• Output Current : 200mA mode : > 200mA (< 2Ω)
20mA mode : > 20mA (< 2Ω)
• Output Voltage : > 4V at Battery >5.2V
• The specification is defined after enabling zeroing.
2.0 @ 4500 counts
1.5 @ 6000 counts
Resolution
0.1V
Resolution
0.1V
Resolution
0.01Ω
0.1Ω
0.001kΩ
0.01kΩ
18
Accuracy
50 to 60Hz
±(0.5%+5D)
Accuracy
±(0.5%+3D)
Accuracy
±(1.5%+5D) *
±(1.5%+3D)
EN
61 to 1kHz
±(1.0%+5D)
