AGV PISTA GP RR Gebrauchsanleitung Seite 18

2
1
16
9 CROWN PAD
9.1 REMOVAL
Prerequisite: sit down with the helmet upside-down
1
on your knees.
→
→
2
10 WIND
10.1 REMOVAL
Prerequisite: sit down with the helmet upside-down
on your knees.
→
10.2 INSTALLATION
Prerequisite: sit down with the helmet upside-down
on your knees.
→
AND INSTALLATION
To remove the crown pad, unfasten the two
front (1) and the rear (2) snap buttons.
To install the crown pad, fasten the two front
(1) and the rear (2) snap buttons.
Before removing the crown pad, make
sure that all the snap buttons have been
unfastened to avoid pulling on the seams
of the fabric parts.
Removing the crown pad is easier if the
cheek pads and wind protection have been
removed from the helmet beforehand.
PROTECTION
To remove the wind protection, pull it by
grasping its central area, then detach it from
the helmet by pulling out the plastic hooks.
First the side ones (1), then the central ones
(2).
To install the wind protection, install the
plastic hooks in their slot inside the chinguard.
First the central ones (2), then the side ones
(1).
