1
8
4 Race3 VISOR
Polycarbonate with variable (4mm - 5mm)
thickness
Anti-scratch treatment on both sides
Optical quality class 1
3
Field of vision: 85° vertical; 190° horizontal
Double-engagement central button-type
locking mechanism with micro-opening
position and fastening adjustment
Inner surface moulded to accommodate the
Pinlock
2
1
4.1 OPERATING POSITIONS
1 Visor closed
2 Visor in micro-opening position (cfr. 4.4)
3 Visor open
4.2 REMOVAL
Prerequisite: the visor is in the fully open position.
2
Start the operation on the right-hand side visor
mechanism.
120 anti-fog lens
®
When riding, it is always advisable to keep
the visor completely closed.
If the helmet is not used for a long time, it
is advisable to leave the visor in the micro-
open position.
Pull the spring catch slider (1; arrow) and
•
move the visor (2) away from the shell.
Repeat the operation on the visor mechanism
•
on the left side.
The visor is detached and removable.
→
