Wall Mounting (Fig. 3a - 3b)
Measure the distance from the holes in the wall mounting brackets, mark out the same distance on the wall and
drill holes for the screws, making sure the holes are level. Screw an appropriate screw into each hole, hang the
screen from the screws with the holes in the brackets. Check the screen is evenly spaced from the wall with a
spirit level.
Screen operation
Lowering the projection surface
Attach the cord to the metal handle at the bottom of the
screen and secure with a double knot. Next, lower the screen
carefully using the cord, until the projection surface reaches
the desire position. The height of the projection surface is
adjustable with 7 centimetre precision.
Fig. 5
Notes:
Avoid touching the projection surface with your fingers or sharp edges because it can be easily damaged.
If the screen gets dirty, clean it using a moist piece of cloth.
Please handle your projection screen with care.
The screen was designed for operation by adult users. Children should not be allowed to tamper or play with
this product.
The screen must be installed in line with this manual. Incorrect installation may cause injury to
people or animals or result in property damage.
Fig. 3a
Winding up the projection surface
Pull the handle and slightly lower the projection surface by
additional 3 or 4 cm until the position lock is released. Next,
while securing the movement of the projection surface by
holding the cord, allow the screen to roll up gently back into
the casing at its top (Fig. 5).
CAUTION: Misuse of the screen or rolling it up without
holding the cord will void the warranty.
Wall mounting method
Fig. 3b
Fig. 4
Casing
7cm
