IMPORTANT!
Please read these instructions thoroughly before the first use of the screen and keep it for future reference.
Packaging materials included with this product are not supposed to be used as toys. Please keep them away
from children.
Screen installation
Take the screen and hold it horizontally at the appropriate
height of your wall or ceiling. Use a spirit level to make sure
it is perfectly horizontal (Fig. 1).
Wall Mounting (Fig.
Use a pencil to mark the drilling points on wall
surface through the installation holes at both ends
of the screen casing. Next, put the screen aside
and drill the holes in the wall at the points
marked. Place plastic dowels in the holes and
attach the screen to the wall using the included
screws (Fig. 2).
Ceiling Mounting (Fig. 3)
Use the same procedure if ceiling installation is
required. Each end of the screen's case provides
two holes for ceiling installation (Fig. 3).
CAUTION: Please make sure that the unrolled
screen fabric hangs vertically and does not touch
the casing at any point.
Video / Business 280
Ceiling Mounting
Measure the distance between D-rings, drill holes for screw hooks with the same distance apart, making sure the
holes are in line with each other and parallel with the wall.
Screw the appropriate screw hooks into the holes and hang the screen by the D-rings.
4
MANUAL PROJECTION SCREEN
INSTALLATION AND OPERATION MANUAL
2)
(Fig. 2a - 2b)
Fig. 2a
Fig. 1
Spirit Level
Fig. 2
Fig. 2b
Fig. 3
Ceiling hanging method
