WARNING! Risk of injury! Before start-
ing work check the area and remove all
objects which may be kicked up by the unit.
Check to make sure the device is in safe operating
condition:
– Check to make sure there are no visible defects.
– Check to make sure all device components are
correctly mounted.
Proper position
Hold the unit
• with the left hand on the front handle,
• and the right hand at approximately hip level on
the operating handle,
• balanced in a comfortable way.
Setting the length of the unit
► P. 4, fig. 7
– Slacken the coupling nut (12).
– Pull the telescopic pole (20) to the desired length.
– Retighten the coupling nut (12) again.
Setting the angle of the cutting head
► P. 4, fig. 3
– Press in and hold the locking button (11).
– Tilt the cutting head (10) to the required position.
– Release the locking button (11) again.
Switching on and off
– Switching on: Press the switch lock (2) and simul-
taneously press the On/Off switch (1).
– Switching off: Release the on-off switch (1).

Cleaning and maintenance

DANGER! Risk of injury! Remove the
battery pack before conducting any work
on the device.
Cleaning and maintenance overview
Note: Clean unit immediately after every
use. Dried grass remains are very hard,
and are very difficult to remove.
If necessary
What?
Cleaning the device
Replacing the cutting insert
► P. 5, fig. 8
– Slide the cutting insert (9) inward and push it out
of the pin (21) on the cutting disk (7).
Error/Fault
Device does not work.
How?
Wipe the unit with a damp
cloth.
Cause
Battery not slotted in correctly?
Battery pack discharged?
Battery pack defective?
Is the device defective?
– Place the new cutting insert (9) on the pin (21)
and pull out the insert until it snaps in.

Storage, transportation

Storage
– Store the tool in a dry and well ventilated place.
Transportation
– When dispatching, try to use the original packag-
ing, if possible.
Storing rechargeable batteries
Note: Rechargeable batteries last the
longest when they are well cared for and,
above all, stored at the correct tempera-
tures. However, with increasing age, the
capacity decreases even when stored
correctly. A significantly reduced operat-
ing time despite a full battery indicates
that it has been used up.
• Leaving the battery in an empty state for a long
time may damage it and greatly reduce its capac-
ity.
• Charge batteries before storage to avoid damage
and deep discharges. The optimum charge level
before storage is around 70%.
• If stored for a very long time, check the charge
level regularly; recharge the battery if necessary.
• Store batteries in dry and well-ventilated rooms.
• Protect batteries from moisture and water.
• If possible, store batteries in the following loca-
tions:
– in rooms with smoke detectors;
– not near flammable or combustible objects;
– not near sources of heat;
• The optimum storage temperature is 10–20 °C.
• Batteries must not be stored below 0 °C or above
40 °C as extreme temperatures may cause the
batteries to become damaged.
• Do not expose batteries to direct sunlight.
• Disconnect batteries from the device before stor-
age.
• Do not leave batteries permanently connected to
the charger.

Troubleshooting

DANGER! Risk of injury! Unprofes-
sional repairs may mean that your unit will
no longer operate safely. This endangers
you and your environment.
Malfunctions are often caused by minor faults. You
can easily remedy most of these yourself. Please
consult the following table before contacting the ven-
dor. You will save yourself a lot of trouble and possibly
money too.
Remedy
Slot battery into place.
► Charging the battery pack –
p. 26.
Contact your local vendor.
