GB
When working with tools that cause consid-
erable dust, wear a dust protection mask.
Do not wear protective gloves when working
with the device.
Wear tight fitting clothes when working with
the device.
If you have long hair, cover or wear a hair
net.
Your unit at a glance
Note: The actual appearance of your prod-
uct may differ from the illustrations.
Lithium ion cordless drill/screwdriver
► P. 3, fig. 1
1. Tool holder
2. Torque regulator
3. Rotation direction switch
4. Locking button
5. On/Off switch
Scope of delivery
• Operating manual
• Lithium ion cordless drill/screwdriver
• Battery charger
• Battery pack
• Additional battery pack (only for 351003)
Operation
Charging the battery pack
NOTICE! Risk of damage to the unit! Do
not allow the battery pack to deep dis-
charge.
NOTICE! Risk of damage to the unit! Do
not press the On/Off switch after the device
has deactivated automatically.
Note: The Li-Ion battery pack can be
charged at any time without affecting the
lifetime of the unit. Interrupting the charging
process will not damage the battery pack.
• The battery pack must be charged prior to the first
start-up (charging time: ► Technical data –
p. 23).
– Press in the locking button (4) and remove the
battery from the device (► P. 4, fig. 2).
– Charge up the product by connecting the charger
to the battery pack (► P. 4, fig. 3).
The charging status is displayed by the control
light (6):
• Control lamp (6) lights red = Battery charging.
• Control lamp (6) lights green = Battery fully
charged.
– Slot the battery pack into the device and make
sure it clicks into place correctly.
22
Removing a tool
NOTICE! Risk of injury! Shortly after
being used, the tool may be very hot. Risk of
burning! Allow a hot tool to cool down. Never
clean a hot tool with flammable liquids.
► P. 4, fig. 4
– Hold on to rear sleeve of tool chick (1).
– Open the front sleeve by turning anti-clockwise.
– Remove the tool.
Inserting a tool
DANGER! Risk of injury! Make sure that
when installing the tool that it fits securely in
the clamping chuck and is not at an angle.
– Place the tool as far as it will go into the tool
holder (1).
– Turn the tool holder (1) clockwise and secure.
Changing the rotation direction
NOTICE! Risk of damage to the unit!
Only use the rotation direction switch when
the device is at a standstill.
– To drill and screw screws into place, press the
rotation direction switch (3) to the left (rotation in
clockwise direction).
– To remove screws, press the rotation direction
switch (3) to the right (rotation in an anti-clockwise
direction).
If the rotation direction switch is in the centre position,
the On/Off switch (5) is blocked.
Setting the torque
NOTICE! Risk of damage to the unit!
Only use the torque regulator when the
device is at a standstill.
NOTICE! Risk of damage to the unit! Do
not use the setting [
screws.
The torque of the device can be adjusted to 20 differ-
ent settings by turning the torque regulator (2):
• Settings 1–11 = Low setting for small screws and
soft materials.
• Settings 12–20 = Higher settings for larger
screws and harder materials.
• Setting [
] = For drilling and unscrewing tight
fitting screws. The releasing clutch is without
function during this setting: The device operates
at maximum torque.
Check before switching on!
Check to make sure the device is in a safe operating
condition:
– Check to make sure there are no visible defects.
– Check to make sure all device components are
correctly mounted.
Switching on and off
– To start the tool turning, press the On/Off but-
ton (5).
– To switch the unit off, release the On/Off
switch [5].
]for screwing in
