Tekniska data Installation 65 cm 50 cm Utblåsningsluften får inte ledas in i rökkanal som används för avledning av rökgaser från Fig. 6 bruksföremål, som matas med annat slag av energi, som t ex oljepanna eller vedspis.
Vedligeholdelse og rengøring Fig. 3 Fig. 4 Fig. 5...
Seite 27
Er fedtfilteret rent? installerede produkt. Kan problemet ikke afhjælpes ved hjælp af ovenstående, kontaktes Electrolux Service A/S. Forsøg Forbehold ikke selv at reparere emhætten da ukorrekt reparation Produktansvaret gælder ikke, hvis den pågældende kan være til fare for person og/eller ejendom.
Seite 28
Tekniske data Installation 65 cm 50 cm Fig. 6...
Innehållsförteckning ............. 2 Innholdsfortegnelse ............12 Indholdsfortegnelse ............22 Sisällysluettelo ..............32 Contents ................42 Inhalt .................. 52 Contents Information about safety The hood is destined uniquely for non-professional use in a domestic setting. It complies with international safety quality regulations and requisites. The safety measures cannot, however, eliminate all risks of accidents. Read the instructions, suggestions, and warnings carefully before installing and starting to use the hood.
Seite 44
The filtering version requires an original Type 160 Electrolux filter. The following accessories are supplied together with the hood: 1 cover complete with commands, illumination...
Seite 45
How to use the hood Fig. 2 B C D E has to be used with the carbon filter: Press keys B and G simultaneously for three The best results are obtained using low speed with seconds. The D anti-fat filter LED lights up and normal cooking and a higher speed in the case of then the E carbon filter LED as well.
Fig. 3 An active carbon filter must be used only if the hood is used in the recirculating version (filtering). · An original ELECTROLUX active carbon filter must be used (it can be ordered from your ELECTROLUX assistance service). · This kind of filter cannot be cleaned or regenerated.
The hood must be disconnected from the power supply when changing the lamp. Carry out the change in this way (Fig. 5): · Remove the protective glass of the lamp with a screwdriver. · Substitute the lamp with an equivalent one. Fig.
Technical data External motor (external installation) 942 121 135 External motor (external installation) 942 121 182 Installation Warning! Check that the aspiration hood is not damaged. Damage due to transportation must be immediately communicated to the transport company. Damage, defects, and eventual missing parts must be immediately communicated to the dealer.
Seite 49
Installation Position the holing diagram to the wall at the correct height (fig.7). The lower corner of the diagram corresponds to the lower corner of the aspiration hood There is a line on the holing template that corresponds to the centre of the apparatus. Trace a line up to the ceiling to facilitate the installation of the hood (fig.
Seite 50
Remove the support from the telescopic flue 3,5 x 13 by unscrewing the two screws that fix it to the flue (one per side - save the screws - Fig. 10). Remove deflector F from the support by unscrewing the 4 screws that fix it to the support (save the screws - Fig.10).
Seite 51
External motor (for external installation) Concerns only the EFCR 942 model. 942 121 135 The hood is not equipped with an internal motor External motor (for external installation) and must be connected to an external motor (to 942 121 182 purchase separately).
Seite 57
· · Abb. 5 · Funktionsstörungen Bei eventuellen Rückfragen und Störungen rufen Sie bitte unseren Kundendienst an (siehe Kundendienst-Stellenverzeichnis). Geben Sie beim Anruf an: Die Modellbezeichnung Die Produktnummer Das Kaufdatum Diese Daten finden Sie auf dem Typenschild nach Öffnen der Fettfiltergitter auf der Innenseite des Gerätes.
Seite 64
The Electrolux Group. The world´s No.1 choice. The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines,vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
