Start-up
To pair the device, proceed as follows:
• Open the Homematic IP app on
your smartphone.
• Select "Add device".
• Open the battery compartment (F)
by pulling the latch back slightly
and remove the battery compart-
ment cover (I).
• Pull the insulating strip out of
the battery compartment of the
Homematic IP Combination Signal-
ling Device. Pairing mode is active
for 3 minutes.
You can start pairing mode manu-
ally for another 3 minutes by brief-
ly pressing the system button (C).
The device appears automatically in
the Homematic IP App.
• To confirm, enter the last four di-
gits of the device number (SGTIN)
in your app, or scan the QR code.
The device number can be found
on the sticker supplied or attached
to the device.
• Wait until pairing is completed.
• If pairing was successful, the LED
lights up green. The device is now
ready for use. If the LED lights up
red, please try again.
• In the app, give the device a name
and allocate it to a room.
• Close the battery compartment (F).
6.2
Power supply
You have the option of supplying the
Homematic IP Combination Signal-
ling Device with power using the 1.5 V
LR14/Baby/C batteries already inserted
or using a suitable plug-in mains adap-
ter (5 VDC/1.5 A/7.5 W max.).
To operate with batteries, proceed as
follows:
• Remove the insulating strip from
the battery compartment (F).
To operate with a plug-in mains adap-
ter, proceed as follows:
• Open the battery compartment (F)
by pulling the latch back slightly
and remove the battery compart-
ment cover (I).
2
1
Figure 2
• Remove the batteries from the bat-
tery compartment (F).
