DEVICE INSTALLATION (FIGURE 3)
WARNING This appliance contains a UV-C emitter.
• Unintended use of the appliance or damage to the housing may result in the escape of dangerous UV-C radiation.
UV-C radiation may, even in little doses, cause harm to the eyes and skin.
• Appliances that are obviously damaged must not be operated.
• Never place the installation at an altitude of more than 2000 meters above sea level.
Decide where you want to mount the device. The best place to install the UV-C device is directly after the filter(s). See
the schematic diagram in the operating instructions. Make sure there is always water flowing through the device when
the lamp is on. Never install the device in direct sunlight.
Install the device in a dry, well-ventilated enclosed space. The device can be installed either horizontally or vertically,
provided that the water flow is from bottom to top (see schematic diagram at the beginning of the instructions for
use), with 30 cm of unobstructed space on the side opposite the lamp connection for future maintenance. At least one
metre of unobstructed space must be left on the side with the lamp connection for convenient future replacement of
the lamp (K) without having to disconnect the entire device.
CAUTION: All connections and couplings must be hand-tight. Do not tighten them with tools. Otherwise damage may
occur.
1. Unscrew the nut (N) from the housing (U). Remove the UV-C lamp (K) from the supplied tube (see packaging) and
carefully slide the lamp into the quartz sleeve (M). Place the lamp (K) with the contact pins in the lamp fitting (L)
and then tighten the nut (N) on the housing (U).
2. Fit the supplied pipe clamps (O). Then insert the unit into the pipe clamps. Tighten the three-piece coupling (I)
firmly, while ensuring the correct position of the sealing rings (P), both at the connections and the quartz sleeve
(see figure 3).
3. Mount the unit in the circuit by means of the three-piece coupling (I). The glue connections of the three-piece
coupling are Ø63 mm or 2". A hose tail adapter can also be used.
ATTENTION: Allow the glued parts to evaporate for 8 hours.
4. Insert the plug of the UV-C device into an earthed wall socket that is protected by a 30 mA residual-current device.
5. Look through the transparent parts of the device to make sure the lamp is lit.
6. The device is shut off when power is disconnected from the device.
*FOR 140 W AMALGAM ONLY
• The glue coupling for the flow switch (V) must be positioned on the three-piece coupling (I) with the screw thread
(W) facing up (see figure 3). The glue coupling (V) can be glued to a three-piece coupling (I). Mount the flow switch
(X) which is attached to the electrical section (S) directly to the screw thread (U) of the glue coupling (V) (see figure 2).
If the flow switch is mounted differently, the device will not work. The arrow on top of the flow switch (X) must always
point in the direction of water flow. If it points in the direction opposite the water flow, the UV-C device will remain off.
• When no water is flowing through the device, the flow switch automatically switches the unit off.
