MORIA EVOLUTION 3E Benutzerhandbuch Seite 11

VII. LABELING INFORMATION
CATALOGUE NUMBER OR SKU
XXXXXX
SERIAL NUMBER
XXXXXXXX
DATE OF MANUFACTURE
YYYY/MM/DD
MANUFACTURER
XXXXXXX
CAUTION : CONSULT INSTRUCTIONS FOR USE FOR ANY IMPORTANT INFORMATION
ABOUT THE SECURITY
XXXXXX
CONSULT OPERATING INSTRUCTIONS
XXXXXX
DISCARD IN A SEPARATE COLLECTION BIN
WARNING AGAINST ELECTROSTATIC DISCHARGES
WARNING AGAINST INTERFERENCE RISK
REFER TO USER MANUAL
SIGN OF GENERAL SAFETY
ALTERNATIVE CURRENT
TYPE « BF » APPLIED PARTS: PROTECTION AGAINST ELECTRIC SHOCK :
• LEAKAGE CURRENT
• GROUNDED POWER SYSTEM
NORMAL CONDITIONS OF USE
75%
40°C
EVO3E CONTROL UNIT AND MOTORS/TURBINES:
TEMPERATURE: 10°C – 40°C / 50°F – 104°F, HUMIDITY RATE: 30 - 75%
10°C
30%
70%
NORMAL CONDITIONS OF USE
35°C
SINGLE USE ITEM :
15°C
TEMPERATURE: 15°C – 35°C / 59°F – 95°F, HUMIDITY RATE: 30 - 70%
30%
IP X6
FOOTSWITCH PROTECTED AGAINST POWERFUL WATER JETS
IP X8
FOOTSWITCH PROTECTED AGAINST WATER SUBMERSION BEYOND 1 METER (3,3 FEET)
THIS SIDE UP
FRAGILE
KEEP DRY
CAUTION FOR USA ONLY: US FEDERAL LAWS RESTRICT THIS DEVICE TO SALE BY, OR ON
THE ORDER OF, A PHYSICIAN.
All manuals and user guides at all-guides.com
VIII. INSTALLATION AND CONNECTION
A. INSTALLATION RECOMMENDATIONS
Following is a list of general recommendations when installing the EVOLUTION 3E console:
• Make sure the console is installed no more than 2 meters away from user
• The console must remain in front of user during operation to visualize every indication (value,
warning)
• User must be able to hear signals from EVOLUTION 3E console properly
• User must be able to disconnect suction from aspiration tubing connector
• User must be cautious about EVOLUTION 3E console displacement due to its height, dimensions
and connections
• The EVOLUTION 3E console must not be installed above or close to a radiating device.
• All applied parts must be used in normal condition of use, and on a routine surgical basis with
respect to their intended use according to the instructions for use.
WARNING : The microkeratomes electric motors and turbine can reach a temperature over 41°C.
Moria recommends to use the motors and rings not longer than 1 min and to prevent any contact of
motors with patient tissues.
B. ELECTRICAL SETTING
Steps
1
2
3
What to do
IMPORTANT WARNINGS
Using the screw Finger tight only
connector, plug in the
footpedal connector
(#19361, 19381,
19381C, 19281J) to the
rear panel of the console
Connect the power NEVER OPERATE WITHOUT MAIN POWER SUPPLY.
supply cord to the main Before using the EVOLUTION 3E, check if position of operating
power supply voltage (115 or 230V) is appropriate to your country's power supply:
- for a power supply of 100-120V: select position «115V»
- for a power supply of 220-240V: select position «230V».
To select position of operating voltage, see chapter XI.A.
To change fuses, see chapter XI.C.
If the unit has not been operated for four weeks or more, the battery
level should be checked and recharged prior to use.
To avoid electrical shock, the console must only be connected to a
grounded power system.
Position the console so that displays, connections and buttons
remain visible and accessible.
Always allow an easy access to the electric supply and power
socket.
In cases of emergency, disconnect the power socket or the supply
cord connector.
Switch on the control Visually check all LEDs are blinking (A3, A4, A5, A7, A9, A10, A11,
unit turning B9 button A12, A14, A15, A16, A17, A18).
to "ON" Visually check A9 and A11 LEDs are ON.
The display indicates the atmospheric pressure (approximately
760mmHg at sea level).
Related
B8
C
B11
B9
LEDS (A9
and A11)
ON
7
#65060/INTL-K-10.2020 MORIA
