Mounting Instructions Pulsoflex "EM"
We are delighted that you have chosen the broncolor Pulsoflex. You are now in possession of a
high quality product. With proper care, it will render you many years of good service.
Mounting
Start by inserting the 4 rods into the fabric channels (1) from the front (6). The rods (2) should
not be inserted completely, but left protruding approx. 10 -15 cm.
Place the bayonet ring in the cover of the Pulsoflex reflector and put the very ends of the rods
(4) into the planned holes (see fig. A) of the backplate.
Pull the cover of the reflector up along the fabric channels as far as possible to the front and put
the respective "cap" (5) on the end of the rods.
Install the diffuser or the special accessories.
Finished !
Accessories
Adapter ring with integrated reflector
Adapter ring without reflector
Set of barn doors to Pulsoflex EM 80x80
1)
When using the adapter ring with integrated reflector the softbox has an accentuated centre
light (approx. 1 f-stop more light). This can be balanced out with the Pulso G lamp by
defocusing.
ATTENTION
Only Pulsoflex soft boxes with an edge length of at least 80 cm may be used with the broncolor
HMI lamp base F575.800. In addition only the adapter ring with integrated reflector may be
inserted.
Bron Elektronik AG
CH-4123 Allschwil
Schweiz (Switzerland)
1)
1)
MI004.00 - 08.08
No. 43.100.00
No. 33.400.00
No. 33.250.00
