5. Fitting the Coarse Filter
If you have dismantled the coarse filter for more
thorough cleaning, proceed as follows. Otherwise, see
"6. Assembly of the Filter Unit".
5.1 Reattach the inner part of the coarse filter.
5.2 The coarse filter only fits in one position on the
holder on the plate. Note the 4 guides and the latch-
ing lug. Insert the coarse filter so that the latching
lug points in direction .
5.3 When the 4 guides are fully pressed into the re-
cesses, turn the coarse filter in direction .
WARNING:
• Remove the battery pack before cleaning to avoid accidental
switch-on!
• Under no circumstances should you immerse the motor housing
in water in order to clean it. Otherwise this might result in an
electric shock or fire.
CAUTION:
• Do not use a wire brush or other abrasive objects.
• Do not use harsh or abrasive cleaning agents.
• The individual components are not suitable for clean-
ing in the dishwasher.
• The housing of the appliance and the accessories can
be wiped with a slightly damp cloth.
• The power supply unit can be wiped with a dry cloth.
Floor Nozzle
1. Disconnect the floor nozzle
from the suction pipe.
2. Turn the floor nozzle around,
so that you see the lower side.
3. Slide the lever in the direction
of arrow to open the lock.
Open the lock.
4. Pull out the brush roller.
5. Remove threads and hair
wound to the brush. Use
scissors, if required.
6. Assembly:
6.1 Reinsert the brush roller, with its star-shaped recess
first, into the compartment.
16
PC-BS3136A_IM 10.2024
6. Assembly of the Filter Unit
6.1 Place the coarse filter in the dust container.
6.2 Place the fine filter back inside the coarse filter. The
mark must point upwards.
6.3 Then reattach the dust container to the handset.
First place the dust container on the motor housing
before snapping the front part back into place. The
connection must engage audibly.
- The rotating brush roller must also be cleaned regularly.
( "Cleaning" / "Floor Nozzle")
A dirty brush roller can reduce the suction power and
increase the rechargeable battery consumption.
Cleaning
6.2 Insert the other end of the brush roller into the
recess under the lock with the curved side facing
downwards.
7. Close the lock of the brush roller. The lock must engage
audibly. Make sure the brush roller is properly placed
before using the floor nozzle again.
Dust Container with Filter Unit
Please read the chapter "Maintenance" for cleaning of these
components.
• Clean the appliance as described and allow it to dry.
• Use the previously mounted wall bracket for storage.
• We recommend storing the appliance in its original
packaging if you do not intend to use it for a longer
period of time.
- Battery pack service life: Even when switched off,
the battery pack is constantly discharging. If you do
not use the appliance for a long time, recharge the
battery pack at least every 4 to 6 weeks.
- Always store the appliance out of the reach of children
in a well-ventilated and dry place.
- The storage temperature should be between 10 °C
and 20 °C.
Storage
