EuroLite LED PIX-16 TCL Bar Bedienungsanleitung Seite 27

6-Channel Mode: All 16 LEDs as 1 segment
CH 1
0 - 21
22 - 32 Red
33 - 43 Yellow
44 - 54 Green
55 - 65 Cyan
66 - 76 Blue
77 - 87 Purple
88 - 98 White
99 - 109 Dream
110 - 120 Meteor
121 - 131 Fade
132 - 142 Change
143 - 153 Flow 1
154 - 164 Flow 2
165 - 175 Flow 3
176 - 186 Flow 4
187 - 197 Flow 5
198 - 208 Flow 6
209 - 219 Flow 7
220 - 230 Flow 8
231 - 241 Flow 9
242 - 255 Sound
Note: When FLOW 8 or FLOW 9 under channel 1 is chosen, you can select the desired color under
channel 4 (0-255).
9- Channel Mode: Every 8 LEDs as 1 segment, 2 segments in total
CH 1 see CH 1 in the
6-Channel Mode
CH 2
see CH 2 in the
6-Channel Mode
CH 3 Flash (0 - 255)
CH 4 R1
CH 5 G1
CH 6 B1
CH 7 R2
CH 8 G2
CH 9 B2
All manuals and user guides at all-guides.com
CH 2 CH 3
Dimmer
(CH 1, 0 - 98)
Speed
(CH 1, 99 - 241) Flash
(0 - 255)
Sensitivity
(CH 1, 242 - 255)
depending on the
setting of
channel 1
27/32
CH 4 CH 5
Red Green
(0 - 255) (0 - 255)
Color select
Color select
