Scanner software

The scanner software is installed in the scanner's panel PC, and runs automatically when you switch on the panel PC.
The first screen that you see is divided into three main sections:
• The viewing section on the left, for previewing scanned images; with nine buttons above it that can be used to change
the preview
• The control section on the right, with four tabs containing options for Copy, Scan, Print and Setup tasks
• The toolbar on the bottom, with nine buttons that are described below
The Quit button shuts down the touch screen.
The Online Help button provides information on the use of the scanner.
The File Manager button opens the File Management dialog box.
The Print Queue button accesses the print queue.
The Collate button groups copies into sets.
The Preview button scans the document to preview the image and select an area of interest.
The Reset button resets settings to default values.
The Stop button cancels the current scanner activity.
The Copy button (in the Copy tab) starts copying. In the Scan tab, the Copy button starts scanning.
The Save button (in the Scan tab) saves scanned pdf files.
The Print button (seen in the Print tab) starts printing.
Create a media profile
To create a media profile your printer must be connected to a network.
You can create a media profile only for a paper type that is currently loaded in the printer installed through the network.
The media profile list includes the paper types with existing media profiles and also the paper types currently loaded in
the printer (the latter shown with an asterisk). You can select one of the paper types loaded in the printer and create a
media profile as described below if it is not already created. You cannot change the names of the media profiles.
In order to print, you must first create a media profile, and you must have at least one printer connected to the scanner
over a network.
1. Check that the media profile you intend to create does not already exist in the media profile list. If the media profile
you want to create already exists, you must delete the existing one first before you can install it again.
2. Clean and calibrate the scanner, unless that has already been done recently. See "Scanner calibration" on page 7.
3. Start media profile creation by selecting the
4. Press the Media Profile
Setup
button, and then press the
tab.
Tool button. (Alternatively: Printer > Tool > Media Profile).
