The outside of the device should be cleaned periodically to remove contaminants such as dust etc.
1
Disconnect the device from power and allow it to cool before cleaning.
2
Clean the surface with a soft lint-free and moistened cloth. Never use alcohol or solvents as these may
damage the surface. Make sure that no liquids can enter the device.
3
The device must be dry before reapplying power.
There are no serviceable parts inside. Do not open the housing. Do not try to repair the device by yourself as this
may result in damage. Maintenance and service operations are only to be carried out by authorized dealers.
Should you need any spare parts, please use genuine parts. Should you have further questions, please contact
your dealer.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
1
Disconnect the device from power and allow it to cool.
2
Open the fuse holder of the mains connection with a fitting screwdriver.
3
Remove the old fuse from the fuse holder and replace it with a new fuse.
4
Carefully push the fuse holder back into its position before reapplying power.
Power supply:
Power consumption:
Power connection:
Power output:
DMX512 input:
DMX feed-through output:
Attachment system:
Dimensions (L x W x H):
Weight:
Specifications are subject to change without notice due to product improvements.
Pin connection:
Accessories
No. 59006869
No. 58010372
No. 3022785H
CLEANING AND MAINTENANCE
TECHNICAL SPECIFICATIONS
100-240 V AC, 50/60 Hz
5 W
P-Con (blue)
4 x P-Con (gray)
2 x 3-pin XLR plug
8 x 3-pin XLR connector
M10 thread
483 x 160 x 44 mm
Rack installation with 1 U
Mounting depth: 23 cm
2.3 kg
TPC-32 Coupler, black
Safety Bond UNV-5 3x600mm up to 5kg silver
DMX cable XLR 3pin 3m bk
31 • EN
