Outputs
This menu allows you to configure the outputs. Each output can be assigned to one of the two inputs. For quick
operation, the output port buttons (9) can also be used to call up this function.
1) Turn and press the encoder to configure an output.
2) Turn the encoder repeatedly to change the input source.
3) Press the encoder to confirm the selection.
DMX Error Alarm
This menu allows you to configure the sound alarm in case of an error.
Turn and press the encoder to select an option.
OFF: The alarm is off.
ON: If pins 1+2 and 2+3 are short-circuited, an alarm sounds and the status display of the output channel
lights up red.
28 • EN
