Before assembling your product, please take a few minutes to check the contents
Outlet (Hose Returning
Water to Pool)
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. No tools
are required for the assembly.
REF. NO.
1 CONTROL STATION
2 CONNECTOR HOSE
3 HOSE CLAMP
4 CELL HOUSING O-RING
5 CELL HOUSING
6 TITANIUM ELECTRODE O-RING
7 TITANIUM ELECTRODE
8 ELECTROLYTIC CELL NUT
9 TEST STRIPS
When ordering parts, be sure to quote the model number and part numbers.
PRODUCT SPECIFICATIONS
Certifi ed Model Number:
Wattage:
Ideal Salt Level:
Maximum sodium hypochlorite output/hour:
Filter pump minimum and
maximum flow rate:
Limited Warranty:
For pools and filter pumps with 1-¼" (32mm) hose connection fittings.
SAVE THESE INSTRUCTIONS
(130IO) MINI SALTWATER SYSTEM ENGLISH 7.5" X 10.3" PANTONE 295U 06/16/2023
PARTS REFERENCE
and become familiar with all the parts.
8
7
6
5 4
DESCRIPTION
CS2220
20 W
3000 ppm (parts per million)
2 grams/hour
300 gallons/hour (1136 liters/hour) /
1000 gallons/hour (3785 liters/hour)
see "Limited Warranty"
9
3 2
Inlet (Connector Hose
to Filter Pump)
1
QTY. SPARE PART NO.
1
1
2
2
1
1
1
1
1
130
English
A
13092
11873
11489
12947
13088A
13094
13093
13095
19635
