LED Reading
00
01
02 - 11
12
90
91
92
93
"BLANK"
When Code "90" alarm is shown, ensure the timer of the filter pump is set
one (1) hour longer than the Saltwater System.
If the filter pump does not have a built-in timer, the filter pump needs to
be turned on/off manually every day.
SALTWATER SYSTEM STATIONARY MOUNTING
Some countries, especially in the European community, require the product to be secured to
the ground or to a base in a permanent upright position. Check with your local authorities to
determine if there is a regulation in your area regarding above-the-ground swimming pool fi lter
pumps. If yes, then the product can be mounted to a platform using the two holes located in the
base. See drawing below.
The product can be mounted on a cement base or onto a wooden platform to prevent accidental
tipping. Total assembly must exceed 18kg.
1. The mounting holes are 6.4 mm in diameter and spaced 52 mm apart.
2. Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
SAVE THESE INSTRUCTIONS
(130IO) MINI SALTWATER SYSTEM ENGLISH 7.5" X 10.3" PANTONE 295U 06/16/2023
LED CODE CHART
Definitions
Stand-By Mode (Start-up)
Minimum Operating Hour (1 hour remaining)
Operating Hours (2 - 11 hours remaining)
Maximum Operating Hours (12 hours remaining)
Alarm Code (Low Pump Flow / No Flow)
Alarm Code (Low Salt Level)
Alarm Code (High Salt Level)
Stand-By Mode (Operating Process finished)
No Power or "Power Saving Mode" waiting to start next
Saltwater System cycle.
IMPORTANT
52 mm
130
English
A
