b. Parts
A
B
C
D
E
6
ANZ
F
USA
European
Adaptor plug
G
L
50cm
H
M
N
I
J
O
P
K
6. Operating instructions
UK
a. On-pump controls
1. Turn on
light showing white (offline) or blue (paired)
2. Pairing
press and hold power button to enter pairing mode (flashing blue light)
3. Choose breast
light showing on L or R side to denote breast
4. Press start/stop
light showing white
5. Battery
each state (solid green, red, pulsing red)
6. Battery (charging)
(solid green or red pulsing)
7. Intensity
left or right toggle - no change to illumination
b. Charging
Charge your pump using the cable and adaptor plug (L) provided before first use.
The USB port is protected by a dust cover and hidden beneath the horn.
Disassemble the pump to charge. For more information, read the Charging
section on the following pages.
c. Horn / flange sizing
We include 24mm and 20mm horns / flanges (A/B) and 17mm and 19mm horn /
flange inserts (O/P) so you can choose the one that is most comfortable for you.
With the horn / flange disassembled from the pump body, place it over your
breast to assess fit. We recommend measuring the diameter of your nipple using
the Tommee Tippee Nipple Size Guide (N) included in the pack so you're familiar
with your size. You may find an insert is required for best results. If you need other
sizes, please visit the Tommee Tippee website where you can order free of charge
alternatives.
7
