CHIEF iCSPSA2 Installationsanleitung Seite 9

Installation Instructions
TOOLS REQUIRED FOR INSTALLATION
PARTS
[single arm mount]
L (2) M (4)
M4 M4
B (1)
[wall plate]
A (1)
G (3)
#10 x2-1/2"
(4.8 x 63.5mm)
N (4) P (4)
3/4"
3/8"
(9.5mm) (19.1mm)
1/8" (3.2mm)
C (1)
[wall plate cover]
H (12)
M4 x 12
Q (4) R (2)
M6 x 12
#8 x 3/8"
(4.0 x 9.5mm)
#2
D (2)
[wall plate cap]
E (1)
[cover]
[adapter bracket]
J (4)
M4 x 20
S (1)
3/16"
(4.8mm)
iCSPSA2
7mm
F (2)
K (4)
M4 x 30
T (1)
3/32"
(2.4mm)
9
