iCSPSA2
2
2
3
12
INSTALL ARM ASSEMBLY TO WALL PLATE
IMPORTANT!
proceed to "INSTALL DISPLAY TO ARM ASSEMBLY" before installing arm
A
assembly to wall plate.
1.
Align arm assembly (A) with wall plate (B) and slide into position.
WARNING:
may allow arm assembly (A) to fall, resulting in serious personal injury or
damage to equipment! Hex head screw should fully recede into arm
assembly hole after tightening.
2.
Using hex key (T), tighten hex head screw in arm assembly (A) ensuring
1
that screw engages one of three holes in wall plate (B).
NOTE:
Three holes are provided in wall plate (B) to provide height
B
3.
Align cover (C) with grooves in wall plate (B) and slide into position.
4.
Align caps (D) with holes in wall plate (B) and slide into position.
2
If installing a display with recessed mounting holes, then
Failure to align hex head screw with hole in wall plate (B)
adjustment.
3
C
B
Installation Instructions
4
D x2
B
