4.
Do not allow pets to roam freely near the stove.
5.
Never leave the stove unguarded when it is alight.
6.
Never allow children to come within reach of the stove.
7.
IN THE EVENT OF MALFUNCTIONING OR IF YOU SMELL GAS, CLOSE THE GAS CYLINDER TAP
IMMEDIATELY.
8.
Do not modify the appliance. Any modification of the appliance may be dangerous and can cause injury or
damage to property. DO NOT make repairs yourself. Repair work on the appliance must only be performed
by qualified personnel.
9.
Sealed parts by the manufacturer or its agent must not be tampered or modified by the user.
10. The appliance becomes very hot during use, it is recommended to use protective gloves (eg oven gloves)
when handling particularly hot components.
11. WARNING: accessible parts can reach high temperatures. Keep the appliance out of the reach of children.
12. Should the air vents become partially or totally blocked, stop using the product immediately, tighten the taps
as described and take the stove to an after-sales assistance centre.
13. WARNING: the maximum diameter of the container to be heated is 240 mm. Do not use containers
with a larger diameter.
14. After a long period of time, check that the rotation of the valve takes place without binding and that the
orifices of the burner tube and the Venturi tube are free of spider webs and spiders' nests.
15. Do not move the appliance during use.
16. Turn off the gas supply at the gas container after use.
These operations must be performed in well-ventilated environments and at a good distance from naked flames
or inflammable materials.
1.
The stove must be connected to the gas cylinder by means of a rubber hose for LPG in conformity with the
standards of the country in which the stove is to be used.
2.
The hose must not be longer than 1.5 m and must be replaced on the basis of the legislation in force in the
country in which the appliance is used.
3.
Always use a low-pressure regulator to connect the stove to the gas cylinder. This MAY ONLY be a fixed
setting regulator normalized according to table previously submitted.
4.
Use a small gas tank 3 kg (minimum) to 15 kg (maximum).
5.
The cylinder should be placed as far as possible from the unit without pulling the tubing.
6.
The hose must be attached to the stove and to the regulator, in countries in which connection is permitted
by the user, by GAS-COMPATIBLE CLOSED MESH METAL CLAMPS.
7.
Ensure that the hose is not to subjected to twisting by placing the gas cylinder in a suitable position with
respect to the stove.
8.
THE HOSE MUST ALWAYS BE REPLACED WHEN IT PRESENTS ABRASIONS OR BURNS.
9.
Place the stove on the ground or on the floor, always in a horizontal position. Never place the stove on
surfaces made of wood, plastic or other inflammable materials.
10. DO NOT TRY TO OPERATE THE STOVE WITH METHANE.
11. WARNING: to avoid a dangerous overheating of the gas pipe, DO NOT install the hose by passing it under
or behind the stove but at the side, keeping it away from the cooking area.
The gas cylinder should not be dropped or handled carelessly! When the unit is not in use, the cylinder must be
disconnected. Cylinders must be stored outdoors in a vertical position and out of the reach of children. Never
place the cylinder in places where the temperature may exceed 50 °C. Do not place cylinders near open flames
or other sources of ignition.
DO NOT SMOKE NEAR THE CYLINDER.
WARNING: the cylinder must be changed outdoors and away from any flame or heat source.
For the installation of the cylinder proceed as follows:
1.
Close the cylinder valve (4).
Check that the stove's valve is closed.
2.
3.
Ensure that there is a seal on the pressure regulator and that it is in
perfect conditions before attaching the regulator on the gas cylinder.
4.
Attach the regulator (1) to the cylinder.
MOD. 1049200 – 1049200V
5.
Insert the rubber tube on the one hand on the receiver cooker (2) and the other on the pressure regulator
and secure with hose clamps (3).
MOD. 1049200D –1049200VD
5.
Screw the crimped tube on one side to the threaded connection of the burner and on the other side on the
pressure regulator.
DT Istr (1049200/ 1049200V) 05/16 – Rev 3_04/2024
INSTRUCTIONS FOR INSTALLING THE APPLIANCE
CONNECTION AND CHANGE CYLINDER
1049200 – 1049200V
8/40
