CS235-20B ELECTRIC CIRCULAR SAW
5) A warning
a) The vibration emission during actual use of the
power tool can differ from the declared total
value depending on the ways in which the tool
is used.
b) Identify additional safety measures to protect
the operator that are based on an estimation of
exposure in the actual conditions of use(taking
account of all parts of the operating cycle such
as the times when the tool is switched off and
when it is running idle in addition to the trigger
time).

6. Specifications and List of Contents

1) Specifications
Model
Power Supply
Motor
Rated input
Rated No Load
speed
Cutter blade size
(Max out. dia. X ins. dia.)
Max.cutting
90°
depth
Weight
(Without Cord)
Cord
2) Standard accessories
Parts name
Guide bar
Wrench
Dust Hood
M4 Bolt
Instruction manual
[7741438] CS235-20B MULTI MANUAL(EN62841)_200831.indd 7 [7741438] CS235-20B MULTI MANUAL(EN62841)_200831.indd 7
Unit CS235-20B
220 - 230 V ~
50/60 Hz
Protective single
- phase series
commutator motor
W 2000
/min 5500
mm 235 X 30
mm 85
kg 7
- 2 core cabtyre cord
CS235-20B
O
O
O
O
O
7. Description of Functions and
Applications
1) Description Function
( See figure 1 )
① Handle ⑨ Angle adjustment knob2
② Switch ⑩ Flange bolt
③ Side Handle ⑪ Washer (B)
④ Blush Cap ⑫ Base
⑤ Saw Blade ⑬ Safety Cover
⑥ Angle adjustment knob1 ⑭ Shaft stopping device
⑦ Gear Cover ⑮ Housing
⑧ Dust Hood ⑯ Guide bar knob
2) Applicaations
a) Cutting in wood.
b) Grooving in wood (use the cutter for electric saw)
c) Cutting in decorative plywood, thick resin plate,
solid new construction materials (use the cutter
blade for plastic).

8. Operating Instructions

1) Mounting/Replacing the saw blade
( See figure 9 )
Disconnect the plug from the power
supply before replacing the cutting
disc to prevent possible accidents
Warning
(power cut-off).
a) Mounting the saw blade
- Clean the saw blade and all clamping parts to be
assembled.
- Tilt back the retracting safety cover and hold
firmly.
- Place the saw blade onto the washer(A). The
cutting direction of the teeth(direction of arrow on
the saw blade) and the direction of rotation arrow
on the retracting safety cover must correspond.
- Mount the washer(B) and screw in the clamping
bolt turning in rotation direction
correct mounting position of washer(A) and
washer(B).
- Press the lock plate and keep it pressed.
- Tighten the clamping bolt with the wrench by
turning in rotation direction
7
EN
. Observe
②
.
②
