5. Installation
Warning: Don't use forward facing before the child's weight exceeds 9kg.
5.1 40-105cm Install Rearward Facing
5.1.1 Check the safety seat is ready to be installed rearward facing(Group 0+1),
pull the backrest reclining handle to recline the seat fully, adjust the angle of recli-
ne to position 2, then release the handle.
5.1.2 It is necessary swivel the seat 180º to place the seat in the opposite directi-
on of travel . Release the backrest rotating handle when the seat is in the desired
position.
5.1.3 Locate the ISOFIX arms in the base of the seat.
5.1.4 Place the seat in the back seat of the vehicle in the opposite direction of
travel.
5.1.5 Hold the safety seat with both hands and insert the two ISOFIX arms firmly
into the vehicle's ISOFIX anchoring points until they fasten with a click on both
sides. The red button will change to green on both sides.
5.1.6 Shake the seat to check that it is correctly anchored to the vehicle's ISOFIX
points.
5.1.7 Pull out the Top Tether and press the tether strap release button to extend
the strap until it is long enough to connect it to the Top Tether anchorage point in
the vehicle. If the Top Tether is tightened favorably and correctly, the button will
change to green.
5.1.8 Make sure the 5-point harness of safety seat has been correctly installed (see
section 4.1)
5.1.9 Open the buckle, put the shoulder harness to the sides, then put the child
into the safety seat. Please check if shoulder harness height is equal to your child's
shoulder height, press the adjusting device and pull the shoulder harness to be
loose, then press the headrest handle to adjust the shoulder harness to the suita-
ble position.
5.1.10 Slide the two tongues together into the buckle. The buckle will not work
well till you hear "click". Adjust the child restraint belt to make sure the lap belt is
well restrained the child's pelvis. Then tighten the shoulder straps by pulling the
adjustable strap at the front of the bottom cushion.
5.1.11 If you want to release your child from the safety seat, press the adjusting
device at the front of the bottom, at the same time pull the shoulder straps. Then
press the red button on the buckle, place the shoulder straps at the side and let
your child out.
