CALL STATION
No.
1 Anti-tamper screw
2 Microphone
3 Infrared LEDs
4 Brightness sensor
5 Camera
6 Back-lit call button
7 Name plate label
8 Speaker
9 Terminal block
10 Speaker volume setting
button
Flush-fitted station
Designation
Prevents the call station from being removed without the assembly
key.
Allows visitors to talk to the residents.
Provide enhanced night vision.
Automatically activates the infrared LEDs when it is dark.
Films visitors and sends the video to the monitor and
smartphone. Angle of vision: H = 102°, V = 68°
Notifies the resident by triggering the ring tone on the indoor
monitor and by sending notifications with a photo of the visitors to
all the smartphones connected to your Somfy Protect account.
Indicates the name on a label.
Allows visitors to hear the residents.
Used to connect the call station to the monitor, to a gate drive
and to a pedestrian door electric latch.
Enables you to set the volume of the call station speaker.
Flush-fitting unit
Description
