FRONT PANEL CONTROLS AND THEIR FUNCTIONS:
USER GUIDE
PHONES OUT (WHERE FITTED)
The phones out is activated from the front panel with the speaker switch, in headphone mode the
speaker is replaced with a resistive load for silent operation.
Volume is controlled with the Master volume in the usual way.
PANEL SOCKETS
On ALL models there is the Mains inlet this is a IEC connector which Must have a Mains lead
plugged into it, - this must be of an approved type and it MUST be the 3 WIRE GROUNDED type
(see safety notes elsewhere in this manual).
SPEAKER OUTPUTS
Speaker outputs are ¼" jack connectors either 8 Ohms or 16 Ohms (note that it is imperative you
do not operate the unit without a speaker plugged in! Unless denoted otherwise).
