Sharp XParty PS-931 Bedienungsanleitung Seite 5

What is included in the box
• XParty Sing PS-931 / PS-932 Party Speaker
• Power cables
• Microphone
• User documentation
Controls
(Refer to 1 on page 2).
1.
– Long press to turn ON/OFF. Short Press to cycle the audio
source (Bluetooth, Aux-in, USB).
2. – EQ effect/Microphone reverb effect on/off
3.
– LED light effects. Press to cycle various LED effects. Press
once more to turn the LEDs off.
Long press to turn the strobe light on/off.
4.
– Play/pause/pair
5.
– Play previous track
6. – Play next track
7.
– Microphone volume controller
8. – Bass boost/Duo mode
9.
– Master volume
10. LED display
Inputs/Outputs
(Refer to 2 on page 2).
1. – USB port for playback
2.
– USB port for charging devices
3.
– Microphone 1 input
4. – Microphone 2 input
5.
– Aux input (3.5mm)
6. – Switch speaker on/off
7.
AC power input (100-240V ~ 50/60Hz)
Operation instruction
Power connection / charging the speaker
This speaker uses a built-in lithium-ion battery pack. Before using it,
charge the battery by connecting the power cable and charge the
speaker for a minimum of three hours.
Risk of product damage! Ensure that the power supply voltage
corresponds to the voltage printed on the back of the speaker. Connect
the power cable to the AC power input of the speaker and then insert
the plug in to a mains power socket.
Turning on/off
To turn the speaker on, put the
the ON position. The button clicks into place for ON and returns to its
original position for OFF.
The speaker is now in standby.
Long press the button for 2 seconds to turn the speaker on.
To put the speaker back into standby, long press the
seconds.
To turn the speaker off, switch the
Controlling the master volume
Rotate the knob to change the master volume level.
button on the rear of the speaker into
button for 3
button to the OFF position.
Connect Bluetooth audio output device
To connect a Bluetooth audio output device (e.g. smart phone or tablet
PC), proceed as follows:
1.
Switch the speaker on.
2.
Press the button once or repeatedly until the screen shows
'bt' to switch to the Bluetooth mode. The speaker is now in pairing
mode. During this time <bt> will flash on the display screen and you
will hear an audio prompt.
3.
Activate your Bluetooth device and select the search mode. "XParty
PS-931" or "XParty PS-932" will appear on your Bluetooth device list.
4.
Once successfully connected, the speaker will give an audio prompt
and <bt> on the screen will be solid.
You can control tracks being played back and the volume of the party
speaker on your external device. The functions available when using an
audio playback device on the party speaker will depend on your device
and the software used.
Press and hold the button (for 3sec.) to disconnect the current
Bluetooth connection. This will be confirmed with an audio prompt.
NOTE:
ū The speaker will attempt to automatically connect itself to the last audio
output device connected via Bluetooth. If this is not possible, the speaker
sends its device identification via Bluetooth and <bt> will flash on the
display.
USB playback
1.
Insert the USB device into
2.
USB mode will automatically be selected.
3. Press or button to select the previous or next track
NOTES:
ū Supported file formats: MP3/WAV/FLAC
ū External hard disks are not supported.
ū Supports USB devices up to 128GB.
AUX-IN
The speaker can be used to listen to audio from external devices.
1.
Connect an auxiliary audio device to the speaker via the 3.5mm Audio
input.
2.
Press the button until the LED display shows <AUX>.
3. Play and control music on the source audio device.
USB charging
The speaker has a built-in 5V 1A charger to charge an external USB device:
1.
Connect the USB plug from the external USB Device to the
port.
2.
To charge the external USB device, the speaker needs to be powered
on.
Connecting a microphone
Before connecting a microphone to
on the speaker is low.
1.
Insert the cord of the microphone supplied into the
the rear of the speaker.
2.
Use the knob to select the desired microphone volume.
EQ / Super bass
Short press the button to cycle equaliser effects that best match
the music style. Select from: FLAT/POP/DANCE/ROCK/LIVE/CLUB.
Long press the button to turn the microphone reverb effect on/
off. The LED display will show <rOFF> for reverb off and <r-ON> for reverb
on.
Short press the SUPER BASS button to boost the bass. Short press again to
turn off. The button will light up when it is on.
USB on the rear of the speaker.
or , ensure the Master volume
or
EN
plug on
