VEVOR HT-A2+ Bedienungsanleitung Seite 13

2. Display Description
Central point
temperature
The highest
temperature
cursor
Maximum value/
minimum value of
field temperature
Color code: used to mark the color corresponding to the relative temperature
from low to high in the field of version.
The central point temperature cursor: used to indicate the central position in
the screen area. The cursor color displays white. The temperature value is
displayed top left corner of the screen.
The highest temperature cursor: used to indicate the highest temperature
position in the screen area. It will move with the movement of the highest
temperature. The cursor displays red. The temperature value is displayed at
bottom left corner of the screen.
The lowest temperature cursor: used to indicate the lowest temperature
position in the screen area. It will move with the movement of the lowest
temperature. The cursor displays green. The temperature value is displayed
at the central position of the screen.
Temperature range Current emissivity
L
10
Battery power
Color code
Temperature
cursor at
central point
The lowest
temperature
cursor
Time
