Removing the Battery
To remove the rechargeable battery, press the battery re-
lease buttons and pull the battery out. Do not use force to
do this.
Battery charge indicator (yellow LED)
Battery
Meaning
charge indic-
ator
Flashing
Charge the battery:
light + sound
You can only drive in 6 to 8 more screws.
Continuous
There is not enough capacity left to drive in
light + sound
another screw or the power tool has over-
loaded:
The power tool can no longer be switched
on.
– Remove the battery and replace it with a
battery that is fully charged.
Flashing
The power tool has overheated and
light
switched itself off:
– Wait a short while for the light to stop
flashing before switching the power tool
on again.
When the rechargeable battery (9) is inserted and the on/off
switch (5) is pressed, the battery charge indicator displays
the battery's state of charge for 5 seconds.
Rechargeable battery charge in-
dicator
Green
Yellow
Red
Recommendations for Optimal Handling of the
Battery
Protect the battery against moisture and water.
Only store the battery within a temperature range of −20 to
50 °C. Do not leave the battery in your car in the summer, for
example.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.
Assembly
Before carrying out any work on the power tool (e.g.
u
maintenance, tool change etc.), remove the battery
from the power tool. There is risk of injury from uninten-
tionally pressing the on/off switch.
Operating and storage conditions
The power tool is suitable only for operation at enclosed
work sites.
To ensure smooth operation, the permitted ambient temper-
ature should be between 0 °C and +45 °C, at a permitted rel-
1 609 92A B6D | (27.01.2025)
ative humidity of between 20 and 95%, free of condensa-
tion.
Suspension device (see figure A)
You can use the hanging hook (11) to attach the power tool
to a suspension device.
– Place the hanging hook (11) on the power tool and click it
into the slots (12).
Regularly check the condition of the hanging hook and
u
the catch in the suspension device.
Configuring the power tool
You can configure various settings on the power tool (e.g. ro-
tational speed, screwing stage, repeat protection) using
BOSCH EXACT Configurator software of version 5.2 or
higher. The power tool must be connected to a PC via its
USB port in order to do this. Use a USB cable for this:
USB 2.0 Type A/Micro-USB 2.0 Type B
– Double-shielded
– Max. length 1 m
When configuring via the USB port, radio interference may
occur outside the industrial environment.
Observe all safety notes and instructions in the software
u
operating instructions.
Changing the tool (see figure B)
When fitting an application tool, make sure that it is
u
held securely in the tool holder. If the application tool is
Capacity
not held securely in the tool holder, it may become loose
and consequently uncontrollable.
60–100 %
Inserting the Application Tool
30–60 %
Only use application tools with the matching shank (1/4"
0–30 %
hexagon).
– Pull the sleeve of the quick-change chuck forwards.
– Place the application tool into the tool holder (1) and re-
lease the quick-change chuck again.
Removing the application tool
– Pull the sleeve of the quick-change chuck forwards.
– Take the application tool out of the tool holder(1) and re-
lease the quick-change chuck again.
Operation
Always set the rotational direction using the rotational direc-
tion switch (6) before starting the power tool:
The power tool will not start if the rotational direction switch
(6) is in the centre (lock-off button).
Setting the rotational direction (see figure C)
– Clockwise: To drive in screws, press the rotational direc-
tion switch (6) through as far as possible to the left.
– Anti-clockwise: To loosen or unscrew screws, press the
rotational direction switch (6) through as far as possible
to the right.
