7. Button Beep

If a button is pressed you shall hear a short beep.

8. Menu Navigation

There are 2 main menus.
- Main menu 1: Setting time and date
- Main menu 2: Setting operating functions
If in display mode, button 1 is pressed long time (1
second), main menu 1 shall be entered.
If in display mode, button 1 is pressed shortly main
menu 2 shall be entered

9. Enter and Navigate Submenus

Main menus can be entered as described above. Once
a main menu has been entered, submenus can be
switched through upward by pressing button 2 and
downward by pressing button 3. At the end of a
menu line it switches to the first entry.
This is the menu tree:
• Main menu 1
1.1 Setting time
1.2 Setting date
• Main menu 2
2.1 Setting alarm time
2.2 Setting duration time is displayed
2.3 Setting duration date is displayed
2.4 Setting cross fade
2.5 Setting different display variants (time 12/24h
and date DD.MM.YY / MM.DD.YY)
2.6 Setting switch off time for night power-down
mode
2.7 Setting switch on time for night power-down
mode
2.8 Blanking of the leading zero
Going through the submenu by pressing button 2 or 3
you can reach the value you want to alter. To enter
and edit a submenu button 1 must be pressed
shortly. The chosen value can now be stepped up by
pressing button 2 and down by pressing button 3. The
value will be set by leaving the submenu.
To leave a submenu, button 1 must be pressed long
time (1 second) and you will return to the main menu.
To then leave a main menu, button 1 must be pressed
long time (1 second) and the clock shall switch back to
display mode.

10. Editing the Parameters

Submenu 1.1: Setting Time

If this menu is entered, the display shows the preset
time.
If the clock is set up to AM/PM mode, nevertheless the
display shall show the time in 24-h mode.
Using button 2 and 3 the chosen digit can be set. To
switch to the next position, button 1 must be pressed.
To confirm this step shifting from digit to digit, the
following digit flashes. After the last digit, the first digit
shall be enabled again.
NOCROTEC – Nixie Clock – The Nixie Queen
The time of the day shall exactly be written into the
memory, when the submenu 1.1 is left. Therefore
the clock can be set exactly on the dot.
Setup Example:
• The time shall be set to 05:25:30 PM = 17:25:30
o'clock.
• Clock is in display mode.
• Press button 1 long time (1 second) to enter the
main menu 1.
• Clock stops and displays the current set time.
• Press button 1 (short) to enter the submenu 1.1.
• Press button 2 (to count up) and button 3 (to
count down) to set the first digit (to '1')
• Press button 1 (short) to jump to the second digit
• Press button 2 and button 3 to set the second
digit (to '7')
• Press button 1 (short) to jump to the third digit
• Press button 2 and button 3 to set the third digit
(to '2')
• Press button 1 (short) to jump to the fourth digit
• Press button 2 and button 3 to set the fourth digit
(to '5')
• Press button 1 (short) to jump to the fifth digit
• Press button 2 and button 3 to set the fifth digit
(to '3')
• Press button 1 (short) to jump to the sixth digit
• Press button 2 and button 3 to set the sixth digit
(to '0')
• Press button 1 long time (1 second) to leave the
submenu 1.1.
• Press button 1 long time (1 second) to leave the
main menu 1.
• Clock starts running in display mode with the set
time.

Submenu 1.2: Setting Date

This submenu is similar to submenu 1.1 except that
current date shall be displayed and edited.
During setting date in this menu the clock shall
always
DD.MM.YY.
If a corrupt date is set (e.g. 31.02.2009) the clock
would accept that date. But at the next change of a
day, the date shall be corrected to any correct one
(e.g. 01.03.2009).
Setup Example:
• Date shall be set to December, 24th 2009.
• Clock is in display mode.
• Press button 1 long time (1 second) to enter the
main menu 1.
• Clock stops and displays the current set time.
• Press button 2 once to reach submenu 1.2
• Press button 1 (short) to enter the submenu 1.2.
• Press button 2 (to count up) and button 3 (to
count down) to set the first digit (to '2')
• Press button 1 (short) to jump to the second digit
• Press button 2 and button 3 to set the second
digit (to '4')
• Press button 1 (short) to jump to the third digit
NOCROTEC
display date in the arrangement
