Upper Panel
Grounding Point
Installation Requirements
Do not operate it in an area that exceeds an ambient
temperature of 75°C.
The installation site should be well-ventilated.
Be sure that the media converter is level and stable to avoid
any hazardous conditions.
The installation site must be free from leaking or dripping
water, heavy dew, and humidity.
Mounting the Converter
DIN Rail Mounting
4
EN
Max. fault loading: 24V, 1A
1
2
3
4
5
6
V1+ V1-
V2+ V2-
DC Input: 12-48V, 3A max.
PWR1
Fault
PWR2
AC Input: 24V, 1.5A max.
Terminal Block Connector
2
1
